Brass Spacers Clearance Spacers



brass_spacers_threaded_spacers brass_spacers_threaded_spacers_1_01



internal_threaded-brass-standoffs-spacers_400



BRASS SPACERS THREADED SPACERS HEX METRIC SPACERS UNF UNC UNEF THREADED SPECAERS NICKEL PLATED ELECTRONIC HARDWARE



 XE       XXXX  -     XXX   -   X   -   X

R or H      Part No.      Thread       |     Finish

Round                              Material

Or Hex

SUCH AS: H104-1003-440-S-Z

  In Inches

Code "E"

Body OD



Part No.

Length



Part No.

Length



Code

Thread



Code

Material

108

1/8



1000

3/32



1041

1-3/4



080

0-80



A

Aluminum

316

3/16



1001

1/8



1042

1-13/16



256

2-56



B

Brass

104

1/4



1002

5/32



1043

1-7/8



440

4-40



S

Steel

516

5/16



1003

3/16



1044

1-15/16



632

6-32



SS

Stainless Steel

308

3/8



1004

7/32



1045

2"



832

8-32



P

POM

102

1/2



1005

1/4



1046

2-1/8



1032

10-32







508

5/8



1006

9/32



1047

2-1/4



1224

12-24







304

3/4



1007

5/16



1048

2-3/8



2520

1/4-20













1008

11/32



1049

2-1/2



3118

5/16-48













1009

3/8



1050

2-5/8



3716

3/8-16



Code

Finish







1010

13/32



1051

2-3/4



4314

7/16-14



PP

Pre-Plating







1011

7/16



1052

2-7/8









O

Plain







1012

15/32



1053

3"









Z

Zinc







1013

1/2



1054

3-1/4









N

Nickel







1014

17/32



1055

3-1/2









A

Anodize







1015

9/16



1056

3-3/4









B

Black Oxide







1016

19/32



1057

4"









T

Tin







1017

5/8



1058

4-1/4



















1018

21/32



1059

4-1/2



















1019

11/16



1060

4-3/4



















1020

23/32



1061

5"



DEPTH OF THREADS







1021

3/4



1062

5-1/4



Thread

Tapped Through

Blind Depth







1022

25/32



1063

5-1/2



Aluminum, Brass, Steel, POM

ST Steel

Aluminum, Brass, ST ST Steel, POM







1023

13/16



1064

5-3/4









1024

27/32



1065

6"



0-80

3/8

1/4

3/16







1025

7/8



1066

6-1/4



2-56

3/4

5/8

3/16







1026

29/32



1067

6-1/2



4-40

1

3/4

3/16







1027

15/16



1068

6-3/4



6-32

1

1

3/8







1028

31/32



1069

7"



8-32

1

1

7/16







1029

1"



1070

7-1/4



10-32

1-1/8

1

1/2







1030

1-1/16



1071

7-1/2



12-24

1-1/8

1

1/2







1031

1-1/8



1072

7-3/4



1/4-20

1-1/4

1-1/4

5/8







1032

1-3/16



1073

8"



5/16-48

1-1/4

1-1/4

5/8







1033

1-1/4



1074

8-1/4



3/8-16

1-1/4

1-1/4

5/8







1034

1-5/16



1075

8-1/2



7/16-14

1-1/4

1-1/4

5/8







1035

1-3/8



1076

8-3/4

















1036

1-7/16



1077

9"











1037

1-1/2



1078

9-1/4











1038

1-9/16



1079

9-1/2











1039

1-5/8



1080

9-3/4











1040

1-11/16



1081

10"







SPEC In Metric





















Code "E"

Body OD



Part No.

Length



Part No.

Length



Code

Thread



Code

Material

04

4.5



M1200

3



M1216

19



2545

M2.5x0.45



A

Aluminum

06

6



M1201

4



M1217

20



3005

M3x0.5



B

Brass

08

8



M1202

5



M1218

21



3505

M3.5x0.5



S

Steel

10

10



M1203

6



M1219

22



4007

M4x0.7



SS

Stainless Steel

13

13



M1204

7



M1220

23



5008

M5x0.8



P

POM







M1205

8



M1221

24



















M1206

9



M1222

25









Code

Finish







M1207

10



M1223

28









PP

Pre-Plating







M1208

11



M1224

31









O

Plain







M1209

12



M1225

34









Z

Zinc







M1210

13



M1226

37









N

Nickel







M1211

14



M1227

40









A

Anodize







M1212

15



M1228

43









B

Black Oxide







M1213

16



M1229

46









T

Tin







M1214

17



M1230

49



















M1215

18



M1231

52































DEPTH OF THREADS



















Thread

Tapped Through

Blind Depth



















Alum, Brass, Steel, POM

ST Steel

Alum Brass, ST ST Steel, POM





































M2x0.4

9

6

4.7



















M2.5x0.45

19

16

4.7



















M3x0.5

25

19

6.3



















M3.5x0.5

25

25

9.5



















M4x0.7

25

25

11.1



















M5x0.8

28

25

12.7



















M6X1

31

31

16
