Copper ‘C’ Connectors Copper Compression Connectors C Type Taps

Run Min |
Run Max | Tap Min | Tap Max | Code | ‘b’ in mm | ‘d1’ in mm | ‘j’ in mm |
16 | 25 | 16 | 25 | A1 EN 25 | 21.4 | 13 | 17 |
35 | 35 | 35 | 35 | A1 EN 35 | 26.6 | 15.6 | 21 |
50 | 70 | 50 | 70 | A1 EN 70 | 34 | 21 | 28 |
70 | 95 | 70 | 95 | A1 EN 95 | 41 | 26 | 29 |
110 | 125 | 110 | 125 | A1 EN 120 | 45 | 28 | 30 |
C Crimp Connectors that are specifically designed for copper tap and parallel connections of stranded copper cables in earthing applications.
“C” type connectors available to achieve earthing-grounding connections on Copper type cable conductors with cross-section areas (CSA) 10sqmm to 240sqmm – installed using appropriate tools. C Type Copper Compression Connectors C type TAPS are high-quality, reliable electrical connectors designed for secure and efficient connections in various applications. They are widely used in power distribution, industrial control panels, and telecommunications. Made from high conductive Copper they help an work as excellent connectors for 2 cables.
C Type Copper Compression Connectors
High-performance C-type compression connectors manufactured from premium-grade copper and copper alloys. Designed for reliable electrical connections in power distribution, industrial, and utility applications. Features precision-engineered compression points for maximum conductivity and mechanical strength.
Material Specifications
- Base Material: Electrolytic Grade Copper (99.9% pure)
- Available Alloys:
- C11000 (ETP Copper)
- C12200 (DHP Copper)
- C10200 (Oxygen-Free Copper)
- C27000 (Yellow Brass for specific applications)
Surface Finish Options
- Bare Copper
- Tin Plated (Standard)
- Silver Plated (For special applications)
- Nickel Plated (Corrosion resistant applications)
Cable Size Range
- Main Cable Range: 16 AWG to 1000 MCM
- Standard Sizes Available:
- 16-14 AWG
- 12-10 AWG
- 8-6 AWG
- 4-2 AWG
- 1/0-2/0 AWG
- 3/0-4/0 AWG
- 250-300 MCM
- 350-400 MCM
- 500-600 MCM
- 700-750 MCM
- 800-1000 MCM
Copper C type connectors, Compression Connectors- Technical Specifications
- Operating Temperature: -40°C to +125°C
- Maximum Voltage Rating: 600V
- Current Rating: As per cable size
- Compression Die Coordination: Color-coded for proper die selection
- Pull-out Strength: Exceeds UL486A-B requirements
- Contact Resistance: <5 micro-ohms
Applications
- Power Distribution
- Transformer terminations
- Switchgear connections
- Panel board installations
- Bus bar terminations
- Industrial Usage
- Motor connections
- Generator terminations
- Heavy machinery power supply
- Control panel wiring
- Utility Applications
- Underground cable joining
- Overhead line terminations
- Substation connections
- Grounding systems
Features & Benefits of Copper C connectors line connectors
- Mechanical Strength
- High tensile strength
- Superior pull-out resistance
- Vibration resistant
- Impact resistant design
- Electrical Performance
- Low contact resistance
- High conductivity
- Stable performance under thermal cycling
- Minimal voltage drop
- Installation Benefits
- Color-coded for easy size identification
- Clear compression point markings
- Installation orientation guide
- Compatible with standard compression tools
