Captive Screws Brass Panel Screws
Price $8.80/Kilogram, FOB , Click to Order Â
We are manufacturers suppliers of Brass Captive Screws Brass electronic hardware fasteners Panel Screws Thumb Screws
| Code number. | Thread size | H.D. | H.L. | L. | T.L. | S.D. | S.L. | W.L. | W. | D. |
| .005 | 0 | .015 | ±.010 | .005 | ±.010 | 0 | 0 | 0 | ||
| -.005 | -.015 | -.015 | 　 | -.005 | 　 | -.01 | -.01 | -.015 | ||
| A101 | 2-56 | 1/8 | 083 | 1/4 | 5/32 | 061 | 3/32 | 062 | 031 | 037 |
| A102 | 2-56 | 1/8 | 083 | 5/16 | 5/32 | 061 | 5/32 | 062 | 031 | 037 |
| A103 | 2-56 | 1/8 | 083 | 3/8 | 5/32 | 061 | 7/32 | 062 | 031 | 037 |
| A104 | 2-56 | 1/8 | 083 | 7/16 | 5/32 | 061 | 9/32 | 062 | 031 | 037 |
| A105 | 2-56 | 1/8 | 083 | 1/2 | 5/32 | 061 | 11/32 | 062 | 031 | 037 |
| A106 | 2-56 | 1/8 | 083 | 9/16 | 5/32 | 061 | 13/32 | 062 | 031 | 037 |
| A107 | 2-56 | 1/8 | 083 | 5/8 | 5/32 | 061 | 15/32 | 062 | 031 | 037 |
| A108 | 2-56 | 1/8 | 083 | 11/16 | 5/32 | 061 | 17/32 | 062 | 031 | 037 |
| A109 | 2-56 | 1/8 | 083 | 3/4 | 5/32 | 061 | 19/32 | 062 | 031 | 037 |
| A110 | 4-40 | 11/64 | 107 | 1/4 | 3/16 | 078 | 1/16 | 079 | 039 | 048 |
| A111 | 4-40 | 11/64 | 107 | 5/16 | 3/16 | 078 | 1/8 | 079 | 039 | 048 |
| A112 | 4-40 | 11/64 | 107 | 3/8 | 3/16 | 078 | 3/16 | 079 | 039 | 048 |
| A113 | 4-40 | 11/64 | 107 | 7/16 | 3/16 | 078 | 1/4 | 079 | 039 | 048 |
| A114 | 4-40 | 11/64 | 107 | 1/2 | 3/16 | 078 | 5/16 | 079 | 039 | 048 |
| A115 | 4-40 | 11/64 | 107 | 9/16 | 3/16 | 078 | 3/8 | 079 | 039 | 048 |
| A116 | 4-40 | 11/64 | 107 | 5/8 | 3/16 | 078 | 7/16 | 079 | 039 | 048 |
| A117 | 4-40 | 11/64 | 107 | 11/16 | 3/16 | 078 | 1/2 | 079 | 039 | 048 |
| A118 | 4-40 | 11/64 | 107 | 3/4 | 3/16 | 078 | 9/16 | 079 | 039 | 048 |
| A119 | 4-40 | 11/64 | 107 | 13/16 | 3/16 | 078 | 5/8 | 079 | 039 | 048 |
| A120 | 4-40 | 11/64 | 107 | 7/8 | 3/16 | 078 | 11/16 | 079 | 039 | 048 |
| A121 | 4-40 | 11/64 | 107 | 15/16 | 3/16 | 078 | 3/4 | 079 | 039 | 048 |
| A122 | 4-40 | 11/64 | 107 | 1″ | 3/16 | 078 | 13/16 | 079 | 039 | 048 |
| A123 | 6-32 | 7/32 | 132 | 5/16 | 7/32 | 095 | 3/32 | 096 | 048 | 060 |
| A124 | 6-32 | 7/32 | 132 | 3/8 | 7/32 | 095 | 5/32 | 096 | 048 | 060 |
| A125 | 6-32 | 7/32 | 132 | 7/16 | 7/32 | 095 | 7/32 | 096 | 048 | 060 |
| A126 | 6-32 | 7/32 | 132 | 1/2 | 7/32 | 095 | 9/32 | 096 | 048 | 060 |
| A127 | 6-32 | 7/32 | 132 | 9/16 | 7/32 | 095 | 11/32 | 096 | 048 | 060 |
| A128 | 6-32 | 7/32 | 132 | 5/8 | 7/32 | 095 | 13/32 | 096 | 048 | 060 |
| A129 | 6-32 | 7/32 | 132 | 11/16 | 7/32 | 095 | 15/32 | 096 | 048 | 060 |
| A130 | 6-32 | 7/32 | 132 | 3/4 | 7/32 | 095 | 17/32 | 096 | 048 | 060 |
| A131 | 6-32 | 7/32 | 132 | 13/16 | 7/32 | 095 | 19/32 | 096 | 048 | 060 |
| A132 | 6-32 | 7/32 | 132 | 7/8 | 7/32 | 095 | 21/32 | 096 | 048 | 060 |
| A133 | 6-32 | 7/32 | 132 | 15/16 | 7/32 | 095 | 23/32 | 096 | 048 | 060 |
| A134 | 6-32 | 7/32 | 132 | 1″ | 7/32 | 095 | 25/32 | 096 | 048 | 060 |
| A135 | 8-32 | 1/4 | 156 | 5/16 | 7/32 | 120 | 3/32 | 113 | 054 | 071 |
| A136 | 8-32 | 1/4 | 156 | 3/8 | 7/32 | 120 | 5/32 | 113 | 054 | 071 |
| A137 | 8-32 | 1/4 | 156 | 7/16 | 7/32 | 120 | 7/32 | 113 | 054 | 071 |
| A138 | 8-32 | 1/4 | 156 | 1/2 | 7/32 | 120 | 9/32 | 113 | 054 | 071 |
| A139 | 8-32 | 1/4 | 156 | 9/16 | 7/32 | 120 | 11/32 | 113 | 054 | 071 |
| A140 | 8-32 | 1/4 | 156 | 5/8 | 7/32 | 120 | 13/32 | 113 | 054 | 071 |
| A141 | 8-32 | 1/4 | 156 | 11/16 | 7/32 | 120 | 15/32 | 113 | 054 | 071 |
| A142 | 8-32 | 1/4 | 156 | 3/4 | 7/32 | 120 | 17/32 | 113 | 054 | 071 |
| A143 | 8-32 | 1/4 | 156 | 13/16 | 7/32 | 120 | 19/32 | 113 | 054 | 071 |
| A144 | 8-32 | 1/4 | 156 | 7/8 | 7/32 | 120 | 21/32 | 113 | 054 | 071 |
| A145 | 8-32 | 1/4 | 156 | 15/16 | 7/32 | 120 | 23/32 | 113 | 054 | 071 |
| A146 | 8-32 | 1/4 | 156 | 1″ | 7/32 | 120 | 25/32 | 113 | 054 | 071 |
| A147 | 8-32 | 1/4 | 156 | 1-1/16 | 7/32 | 120 | 27/32 | 113 | 054 | 071 |
| A148 | 8-32 | 1/4 | 156 | 1-1/8 | 7/32 | 120 | 29/32 | 113 | 054 | 071 |
| A149 | 8-32 | 1/4 | 156 | 1-3/16 | 7/32 | 120 | 31/32 | 113 | 054 | 071 |
| A150 | 8-32 | 1/4 | 156 | 1-1/4 | 7/32 | 120 | 1-1/32 | 113 | 054 | 071 |
| Code | Material | Code | Finish | |||||||
| A | Aluminum | PP | Pre-Plating | |||||||
| B | Brass | O | Plain | |||||||
| S | Steel | Z | Zinc | |||||||
| SS | ST Steel | N | Nickel | |||||||
| 　 | 　 | A | Anodize | |||||||
| 　 | 　 | B | Black Oxide | |||||||
| 　 | 　 | T | Tin |
